[ High Efficiency ] Composite material impeller optimized by ternary flow CFD fluid simulation technology, reasonably designed flow runner combined with ultra-efficient motor create the high efficiency of the fan.
[ Low Noise ] The designer closely combines aerodynamics and sound source, and makes the blade angle and blade pattern fully adapt to the ternary flow field, which always ensures lower noise at the same air volume.
[ High Reliability ] Motors have F class insulation, and been tested for 3 months of 65℃ high temperature test and 40,000 hours of life test, which ensure worse-free quality.
[ Accurate Intelligent Control ] The fan has efficient AC/EC/DC motor for option and supports various control modes such as motor wiring regulation / 0~10V / PWM / RS485 to accurately meet the ventilation needs of different period of time.
[ Wide Application ] The products is used wherever outstanding performance is required, for example, household air conditioning, ventilation, fresh air purification, range hood and other household appliances, rail transit and more.
[ Variety of Models ] Available in dimensions of : 120mm~180mm, this allows for air flow rates of up to 958m3/h and static pressure of up to 800Pa.
| Quantity: | |
|---|---|
F160M.D001
EBST
F160M.D001
Product Parameters |
| Material: | Impeller: Galvanized sheet steel |
Direction of rotation: | Clockwise, seen on rotor |
| Control input: | Motor wiring speed regulation |
Type of protection: | IP 42 |
Insulation class: | F |
Bearing: | Maintenance-free Ball bearings |
Approval: | CCC |
Amb.Temp: | -25~+60℃ |
Model | Curve | Voltage [V] | Max Current [A] | Speed [rpm] | Max Power [W] | Max Airflow [m3/h] | Noise [dB(A)] |
F160M.D001 | A | 48 | 1.92 | 1700 | 92 | 543 | 63 |
 | Ps [Pa] | Airflow [m3/h] | Speed [rpm] | Power [W] | ||
A | ① | 200 | 467 | 2040 | 109 | |
② | 250 | 449 | 2130 | 113 | ||
③ | 300 | 436 | 2205 | 116 | ||
④ | 350 | 421 | 2285 | 120 | ||
Application Scenarios |
Product Certificate |
UL Certification
Certified by the authoritative international UL safety mark, the DC forward curved centrifugal fan features high reliability and long service life, suitable for household air conditioning, fresh air purification and other scenarios, meeting the standards of North American and global high-end markets.
CE Certification
Compliant with EU LVD and EMC directives, the DC forward curved centrifugal fan is qualified for EU market access, enabling smoother global application and suitable for diverse scenarios such as household and civil ventilation.
CCC Certification
Complies with China's mandatory product certification standards, suitable for the DC forward curved centrifugal fan. It fully meets electrical safety and EMC requirements, ensuring safer use and adapting to various domestic compliant scenarios such as household air conditioning and range hoods.
CQC Certification
Certified by the China Quality Certification Center (CQC), strict testing comprehensively controls the performance and quality of the DC forward curved centrifugal fan, demonstrating its reliable product quality and being suitable for core scenarios such as household ventilation and fresh air purification.
RoHS Certification
Complies with EU RoHS environmental standards, strictly restricts the content of harmful substances, suitable for the DC forward curved centrifugal fan. It is green and pollution-free, adapting to strict environmental scenarios such as household use, high-end cleanliness and medical care, and protecting the safety of the use environment.
Reach Certification
Certified by the EU REACH regulation, it fully controls the risks of chemical substances in the product, suitable for the DC forward curved centrifugal fan, ensuring compliant export and widely adapting to various global application scenarios such as household and civil ventilation.
FAQ |
Q1：What are the core advantages of the DC forward curved centrifugal fan?
A: Core advantages are summarized in five points: ① High efficiency: CFD-optimized composite impeller matched with a high-efficiency motor delivers excellent energy performance; ② Low noise: Aerodynamic design adapts to the ternary flow field for lower noise at the same air volume; ③ High reliability: F-class insulated motor passed strict high-temperature and long-life tests; ④ Precise intelligent control: Multiple control modes are supported to meet ventilation demands in different periods; ⑤ Complete model range: Sizes from 120mm to 180mm cover various air volume and static pressure requirements.
Q2：What main application scenarios is the DC forward curved centrifugal fan suitable for?
A: It is widely applied in household appliances including air conditioners, indoor ventilation, whole-house fresh air purification and kitchen range hoods; it also supports small commercial ventilation equipment, high-end clean environments and light medical scenarios.
Q3：What is the core function of the DC forward curved centrifugal fan in fresh air purification?
A: As the core power component of fresh air systems, it delivers filtered and purified outdoor air indoors while exhausting harmful indoor gases, maintaining fresh and clean air and improving living health standards.
Q4：Q: How to select the right model of DC forward curved centrifugal fan for different scenarios?
A: Sizes range from 120mm to 180mm. Small sizes such as 120mm fit household air conditioners and desktop fresh air units; large sizes such as 180mm suit scenarios requiring high air volume and high static pressure like range hoods and whole-house fresh air systems (max airflow: 958m³/h, max static pressure: 800Pa).
Q5：What control modes does the DC forward curved centrifugal fan support?
A: It supports precise control methods including wiring speed regulation, 0~10V, PWM and RS485 communication, enabling flexible adjustment according to real-time ventilation needs to balance energy saving and comfort.
Q6：What technical highlights ensure low noise for the DC forward curved centrifugal fan?
A: Optimized with aerodynamics and sound source improvement, the blade angle and profile perfectly match the ternary flow field, reducing airflow noise significantly while maintaining stable air volume for quieter operation.
Q7：How are the service life and high-temperature performance guaranteed for the DC forward curved centrifugal fan?
A: The motor adopts F-class insulation and has passed a 3-month continuous high-temperature test at 65℃ and a 40,000-hour durability test, ensuring stable operation under high temperatures with long service life and trouble-free performance.
