EBST
Model | Voltage [V] | Frequency [Hz] | Speed [rpm] | Max Power [W] | Max Airflow [m3/h] | Noise [dB(A)] | |
 | B280M.A037 | 220 | 50 | 2669 | 268 | 2095 | 73 |
 | B355M.A003 | 230 | 60 | 1635 | 360 | 2890 | 73.8 |
230 | 50 | 1425 | 255 | 2510 | 69.9 | ||
 | B355M.A012 | 380 | 50 | 1417 | 239 | 2891 | 72.8 |
400 | 60 | 1651 | 341 | 3373 | 76.8 | ||
 | B400M.A001 | 380 | 50 | 1440 | 562 | 5034 | 72.8 |
 | B400M.A004 | 230 | 50 | 1445 | 480 | 4430 | 71.5 |
 | B450M.A004 | 380 | 50 | 1405 | 755 | 5867 | 78.8 |
 | B450M.A005 | 230 | 50 | 1405 | 790 | 5900 | 78.8 |
 | B450M.A016 | 400 | 50 | 1424 | 581 | 5992 | 78.9 |
 | B520M.A005 | 380 | 50 | 1365 | 1485 | 8300 | 80 |
 | B520M.A003 | 380 | 50 | 1365 | 1485 | 8300 | 80 |
 | B520M.A011 | 380 | 50 | 1370 | 1073 | 8390 | 80.2 |
 | B560M.A001 | 380 | 50 | 1310 | 2368 | 12315 | 83.9 |
 |  |  |
 |  |  |
Model | A | B | C | D | E | F | G | H | I | J | K | L | M |
B280M.A037 | ∅281 | ∅92 | ∅191 | ∅281 | 145 | 91.5 | 3 | 34 | ∅270 | ∅280 | 4 - ∅4 | ∅58 | 4-M4 |
B355M.A003 | ∅360 | ∅102 | ∅250 | ∅358 | 165 | 147 | 4 | 31 | ∅325 | ∅350 | 6 - ∅4 | ∅90 | 4-M6 |
B355M.A012 | ∅368 | ∅102 | ∅236 | ∅368 | 198 | 119 | 4 | 31 | ∅325 | ∅350 | 6 - ∅4.5 | ∅90 | 4-M6 |
B400M.A001 | ∅420 | ∅138 | ∅300 | ∅420 | 197 | 181 | 10 | 65.5 | ∅345 | ∅370 | 4 - ∅4.5 | ∅115 | 4-M6 |
B400M.A004 | ∅420 | ∅138 | ∅300 | ∅420 | 197 | 181 | 10 | 65.5 | ∅345 | ∅370 | 4 - ∅4.5 | ∅115 | 4-M6 |
B450M.A004 | ∅465 | ∅138 | ∅300 | ∅465 | 234 | 206 | 10 | 70 | ∅425 | ∅450 | 6 - ∅9 | ∅115 | 4-M6 |
B450M.A005 | ∅465 | ∅138 | ∅300 | ∅465 | 234 | 206 | 10 | 70 | ∅425 | ∅450 | 6 - ∅9 | ∅115 | 4-M6 |
B450M.A016 | ∅465 | ∅138 | ∅300 | ∅465 | 238 | 206 | 10 | 70 | ∅425 | ∅450 | 6 - ∅9 | ∅115 | 4-M6 |
B520M.A005 | ∅510 | ∅180 | ∅338 | ∅510 | 268 | 225 | 12 | 40 | ∅445 | ∅470 | 6 - ∅9 | ∅162 | 8-M10 |
B520M.A003 | ∅510 | ∅180 | ∅338 | ∅510 | 295 | 225 | 12 | 52 | ∅445 | ∅470 | 6 - ∅9 | ∅162 | 8-M10 |
B520M.A011 | ∅510 | ∅180 | ∅338 | ∅510 | 267 | 224 | 10 | 40 | ∅445 | ∅470 | 6 - ∅9 | ∅162 | 8-M10 |
B560M.A001 | ∅570 | ∅180 | ∅440 | ∅585 | 291 | 256 | 6 | 83 | ∅540 | ∅565 | 6 - ∅9 | ∅162 | 8-M10 |
All-metal impeller structure, fire-retardant and anti-deformation, avoiding plastic aging and hidden dangers.
High mechanical strength and precise dynamic balance design, ensuring low vibration and long-term stable operation.
Wide temperature resistance and strong environmental adaptability, perfectly matching container and cabinet-type energy storage heat dissipation scenarios.
Excellent high static pressure performance, effectively overcoming duct resistance, filter resistance and dense battery module barriers.
Optimized aerodynamic structure delivers uniform air volume distribution and balanced heat dissipation for battery packs.
Backward curved blade design, with stable operation, low noise and no overload.
Universal AC wide voltage design, compatible with global energy storage power frequency and voltage standards.
High-grade insulation and high-level protection rating, dustproof and moisture-proof, suitable for outdoor and harsh working conditions.
Long service life, 24/7 continuous operability and low maintenance cost for energy storage systems.
Stable and efficient heat dissipation, effectively control battery temperature and prevent thermal runaway risks.
High operating efficiency, reduce overall power consumption and improve energy storage system energy efficiency.
Flexible speed regulation and easy system integration, compatible with mainstream energy storage control systems.
Q: What makes metal impeller fans more suitable for ESS thermal management than ordinary fans?
A: Different from ordinary plastic impeller fans, the all-metal structure features high temperature resistance, impact resistance and flame retardant performance. It adapts to the closed and high-load operating environment of energy storage cabinets and containers, ensuring long-term safe and stable heat dissipation for battery systems.
Q: Can this AC centrifugal fan adapt to high-resistance cooling scenarios of energy storage cabinets?
A: Yes. Adopting backward curved blade design, the fan provides superior high static pressure performance. It can easily cope with dense battery modules, filters and long duct resistance, to ensure stable air supply and uniform heat dissipation.
Q: What are the environmental adaptability and protection levels of the fan for outdoor ESS containers?
A: The fan is equipped with F-class motor insulation and high ingress protection grade. It supports wide temperature operation, with good dustproof and moistureproof performance, fully meeting the harsh working conditions of outdoor energy storage containers and cabinet-type energy storage stations.
Q: Is the AC metal centrifugal fan suitable for 24/7 continuous operation of energy storage systems?
A: Absolutely. With precisely dynamic balance treatment, low vibration and low noise output, plus industrial-grade motor and high-quality structural components, it supports long-term non-stop operation, with long service life and low later maintenance cost.
Q: Does this energy storage dedicated AC fan support system linkage and speed regulation?
A: Yes. It can match mainstream energy storage BMS and EMS systems. With optional speed control methods, it realizes intelligent speed adjustment according to battery temperature, reducing energy consumption while maintaining precise thermal management.
